Horizontal Three-Inlet Floor Drain
Horizontal Three-Inlet Floor Drain
Horizontal drain with three DN40 side inlets and DN50 outlet, designed for connecting multiple wastewater points. This version features stainless-steel grate.
Technical specifications
| Application | Sanitary drainage / floor drainage |
|---|---|
| Installation | Horizontal |
| Article code(s) | HL304 |
| Drainage connection | DN50 outlet; three DN40 side inlets |
| Drain configuration | Floor drain |
| Trap / odour protection | Conventional trap seal |
| Grate / finish | Stainless-steel grate |
| Waterproofing interface | Connection flange / installation interface |
| Manufacturer | HL Hutterer & Lechner, Austria |
Models and official HL technical drawings
| Article code | Connection | HL specification and drawing |
|---|---|---|
| HL304 | DN50 outlet; three DN40 side inlets | Official HL product page | Technical drawing (PDF) |
Refer to the linked HL product pages for model-specific dimensions, rated flow capacities, and PDF technical drawings.
