Vertical Drain Body with Bitumen Membrane
Vertical Drain Body with Bitumen Membrane
Vertical drain body for compatible sanitary drainage installations, with DN50 / DN75 connection(s). This HL version features no grate (body only) and a factory-attached bitumen membrane for waterproofing.
Technical specifications
| Application | Sanitary drainage / floor drainage |
|---|---|
| Installation | Vertical |
| Article code(s) | HL310KH |
| Drainage connection | DN50 / DN75 |
| Drain configuration | Drain body |
| Trap / odour protection | Drain body only |
| Grate / finish | No grate (body only) |
| Waterproofing interface | Factory-fitted bitumen membrane |
| Manufacturer | HL Hutterer & Lechner, Austria |
Models and official HL technical drawings
| Article code | Connection | HL specification and drawing |
|---|---|---|
| HL310KH | DN50 / DN75 | Official HL product page | Technical drawing (PDF) |
Refer to the linked HL product pages for model-specific dimensions, rated flow capacities, and PDF technical drawings.
